¡El SGMICRO IC es de alta calidad! VIN, D1, D2, D3 to GND ...................................... -0.3V to 6V
EN to GND........................................................... -0.3V to 6V
SCL, SDA to GND ....................................-0.3V to VIN + 0.3V
Package Thermal Resistance
UTDFN-1.5×1.5-8L, θJA .......................................... 99.5℃/W
Junction Temperature.................................................+150℃
Storage Temperature Range .......................-65℃ to +150℃
Lead Temperature (Soldering, 10s)............................+260℃
ESD Susceptibility
HBM.............................................................................4000V
MM.................................................................................400V
CDM ............................................................................1000V
RECOMMENDED OPERATING CONDITIONS
Input Voltage Range...........................................2.5V to 5.5V
Operating Temperature Range......................-40℃ to +85℃
Input Voltage Range: 2.5V to 5.5V
Ultra-Low 30mV Dropout Voltage at a 10mA Load per String
Programmable LED Current through I2C Interface
0.125mA to 24mA Current Levels with 0.125mA Steps
Automatic Blink Mode on D1 Pin
Maximum LED1 Current: 8mA
Blinking Period: 2s
Independent Channel Control
ON/OFF State Interval Time Control
RGB LED Color Control
Programmable Ramp-Up and Ramp-Down Time
No Noise and Constant LED Current
Fast and Smooth Startup
Less than 1μA Shutdown Current
-40℃ to +85℃ Operating Temperature Range
Available in a Green UTDFN-1.5×1.5-8L Package
