VECTOR Transmisor SRC-T1
$ 89 .00
✔ En stock (Puede enviarse en 5-7 días)
Cantidad
Pagos
Soporte en línea 24/7
12 meses de garantía para productos nuevos
Garantía de devolución del dinero en 30 días
Product Display
|
Product Description |
|
|
Brand: |
Vector |
|
Model: |
SRC-T1 |
|
Specifications: |
Brand new |
|
Type: |
Servo |
|
Sensor range: |
40~60 °C |
|
Operating Voltage: |
24 V AC 50/60 Hz +10%, 24VDC + 10% |
|
Transformer: |
SELV to HD 384, Class II, 48VA max |
|
Power Consumption: |
Max 2 VA |
|
Terminal Connectors: |
For wire 0.34…2.5 mm2 (AWG 24…12) |
|
Sensing Probe Accuracy: |
0…50°C (32…122°F): 50…60°C (122…158°F): 0.2 K 0.5 K |
|
Allow one hour after power up for compensation swing in |
|
|
Analog Outputs |
|
|
Output Signal: |
DC 0-10V or 0…20mA |
|
Resolution: |
10 Bit, 9.7 mV, 0.019.5 mA |
|
Maximum Load: |
Voltage: ≥1kΩ Current: ≤500Ω |
¡El transmitter measures the temperature by the use of a precision sensing element.
¡El microprocessor samples the temperature once per second.
It calculates an averaging signal over a preset number of seconds
and generates an output signal based on lower and upper signal range values.
Standard range is -40…60°C (-40…140°F) and 10 seconds average.
¡El signal range and the averaging samples may be customized.
¡El
output signal range and type may be customized by jumpers and if required by a programming tool.
Standard
signal ranges are 0-10VDC, 2-10VDC, 4-20mA and 0-20mA.
These ranges can be set by jumpers.
Other ranges
can be set by using the external display and programming module. (OPA-S)
Scope of application
Such as machine tools, printing equipment, packaging equipment, textile equipment, laser processing equipment, robots, electronics, pharmaceuticals, financial machinery, automated production lines, etc.
Product Media
Packing & Shipping
Q: What means of transportation?
A: Courier: UPS, FEDEX, DHL, TNT and EMS; Air transportation; Sea transportation; Land Transpotation. We also offer DDP service for some certain countries and products.
Q: How long is your delivery time?
A: Usually, if it is in stock, it will take 5 to 10 days. Or, if there is no stock, it is 15-20 days, depending on the quantity.
¡El Swiss Vector company specializes in the research and development, production and sales of products in the fields of HVAC, urban heating, district heat exchange, building automation, refrigeration control, etc. ¡El main products are various fan coil controllers, temperature and humidity sensor transmitters, Solenoid valves, etc., to design the intelligent control system of the air-conditioning box.
