Stroke: 1 mm - 2000 mm
Piston diameter: 12 mm
Type code: DGC
Cushioning: Pneumatic shock absorber, hard characteristic curve: Elastic cushioning rings/pads at both ends: Pneumatic shock absorber, soft characteristic curve
Mounting position: Any
Guide: Basic guide: Recirculating ball bearing guide
Position sensing: For proximity sensor
Variants: Additional slide, standard, left: Additional slide, standard on right
Operating pressure: 2.5 bar - 8 bar
Mode of operation: Double-acting
ATEX category gas: II 2G
Type of ignition protection for gas: Ex h IIC T4 Gb X
ATEX category for dust: II 3D
Type of (ignition) protection for dust: Ex h IIIC T120Celsius Degree Db X
Explosive ambient temperature: -10Celsius Degree <= Ta <= +60Celsius Degree
Explosion prevention and protection: Zone 1 (ATEX): Zone 2 (ATEX): Zone 22 (ATEX)
Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-]
Information on operating and pilot media: Operation with oil lubrication possible (required for further use)
CE marking (see declaration of conformity): as per EU explosion protection directive (ATEX)
Corrosion resistance class (CRC): 1 - Low corrosion stress: 2 - Moderate corrosion stress
Ambient temperature: -10 to 60 Celsius Degree
Theoretical force at 6 bar, retracting: 68 N
Theoretical force at 6 bar, advancing: 68 N
Type of mounting: With accessories
Note on materials: Free of copper and PTFE: RoHS-compliant
Cover material: Wrought aluminum alloy
Seals material: TPE-U(PU): POM
